Belarus 100X

.

.

.

The Belarus 100X tractor is designed for agricultural operations with mounted, semi-mounted and trailed machines and implements, for integrated mechanization of cotton cultivation and raw cotton harvesting and also agricultural operations in cotton-growing areas.

.



Additional options:

  • Ceramic-metal clutch pads;
  • Speeder;
  • Automatic coupling;
  • Front axis (4×2);
  • Set of spacers for 2400 mm tread.



Capacity 104,7(107,4) h.p./ 77,0(79,0) кВт
Axle arrangement 3К2
Selective gear mechanical, with the lowering reducer doubling number of transfers
Number of gears FWD/BWD 16/4



.

Technical characteristics

.

Engine
Type the 4th cylinder with a turbo
Capacity, h.p./kW 104,7(107,4)/77,0(79,0)
Brand mark D-245/D-245C
Ecological standard Stage 0/Stage I
Fuel use, g/(kW·h) 236/244
Torque capacity, Н·m2 385,5
Transmission system
Selective gear Mechanical/synchronized, with the mechanical/synchronized raising reducer
Flywheel clutch frictional one-disk constant the closed type with a mechanical control
Number of gears FWD/BWD 16/4
Back PTO shaft, min-1 540/1000
Hydraulics
Load-carrying capacity of back suspension gear on suspension axis, kg, minimum 2800
Full scale pressure, MPa 20-2
Pump displacement at nominal speed of diesel crankshaft, l/min, minimum 55
Hydraulics reservoir capacity, l 25,5 ± 0,5
Undercarriage
Type wheeled
Axle arrangement 3К2
Tyres
front 12-16;13.0/75-16
back 11.2R42; 18.4L30; 18.4R30; 15.5R38
Other specifications
Brakes/trailer brakes dry disk with the mechanical drive / pneumatic, single-wire, blocked with management of tractor brakes
Maximum weight, kg 6500
Climatic modification У1/Т1
Minimum and maximum speed FWD/BWD, km/h Min 2,9/6,5
Max 25/13,6
