- Capacity 116 kW (158 h.p.)
- Selective gear mechanical
- Number of gears FWD/BWD 12/6
Specifications
| Operated Weight, kg | 13900 |
| Overall dimensions (Length/Width/Height), mm | 6250/2916/2950 |
| Travel speed (forward/reverse), km/h | 1,36 – 14,9/1,9 – 7,1 |
| Ground clearance, mm | 360 |
| Engine | |
|---|---|
| Capacity, kW (h.p.) | 116 (158) |
| Brand mark | ММЗ Д-260.1S2 |
| Ecological standard | Tier II |
| Fuel rate at rated power, g/(kW·h) | 249 |
| Transmission system | |
| Number of gears FWD/BWD | 12/6 |
| Back PTO shaft | independent II, rpm |
| Hydraulics | |
| Hydraulics reservoir capacity, l | 70 |
| Breast | |
| Overall dimensions, mm: width/weight | 2916/1175 |
Performance
| Description | 1502-00 | 1502-01 | 1502-02 | 1502-03 |
|---|---|---|---|---|
| Appointment | Industrial | Reclamation | Industrial | Reclamation |
| Blade | Direct | Rotary | Direct | Rotary |
| Broadened caterpillar | x | x | ||
| ВОМ | x | x | x | |
| Air Conditioning | x | x | ||
| Weight, kg | 13900 | 15000 | 13500 | 15000 |
| The greatest average conditional -tion pressures caterpillar drives on the ground, kPa | 51,0 | 44,9 | 50,0 | 44,0 |
| Dimensions of blade | ||||
| Width, mm: | 2916 | 3630 | 2916 | 3630 |
| Height , mm: | 1175 | 1240 | 1175 | 1240 |
| Blade type | direct | rotary | direct | rotary |
